Vehicle Interior Air Quality – Quality You Can Breathe
The air we breathe in our vehicles has a direct impact on our well-being. Inside modern vehicles, volatile organic compounds (VOCs) released from materials and components can significantly impair the air quality and cause unpleasant odors.
To keep these emissions to a minimum, vehicle manufacturers (OEMs) define specific quality requirements for all components used in the vehicle – in particular for VOCs and odor emissions. Compliance with these requirements is verified using various high-precision laboratory test methods that vary depending on the type and properties of the materials.
Targeted test methods to ensure healthy interior air quality
The OEM-specific test procedures focus on the identification and quantification of chemical substances that are released from vehicle interior materials and components under defined conditions. These analyses are supplemented by sensory inspections that detect unpleasant odors in advance, thus ensuring an air quality that lasts.
In addition to general VOCs, the main focus is on formaldehyde, as this substance is subject to particularly low emission limits:
- OEM-specific requirements to minimize formaldehyde emissions
- Future REACH limit value: 0.062 mg/m³ in vehicle interiors
These specifications are intended to protect vehicle occupants and impose high standards on the materials used. We will draw on our comprehensive expertise to help you meet these requirements. In our DIN EN ISO 17025 accredited TÜV Rheinland Group emissions laboratory, we carry out all standard test methods in accordance with OEM specifications – precisely, reliably and in compliance with the standards.
Our services at a glance
VOC emissions – Test chamber method
Method for determining the emission behavior of components under controlled laboratory conditions.
Test standards:
- VW PV3942 / VW50180
- BMW GS 97014-3
- Hyundai/Kia MS 300-57
- ISO 12219-4
Additional methods for determining the types and concentrations of emitted VOCs and carbonyl compounds:
- DIN EN ISO 16000-3 (carbonyl compounds)
- DIN EN ISO 16000-6 (VOC screening)
Formaldehyde emissions testing – Bottle method
Simple, reliable method for determining formaldehyde emissions from materials.
Test standards:
- VW PV3925
- VDA 275
Note: Future limit value for vehicle interiors according to REACH: 0.062 mg/m³.
VOC emissions – Sampling bag method
Method for quality control and verification of compliance with OEM specifications for VOC emissions from components and materials.
Test standards:
- ISO 12219-2
- ISO 12219-9
- Jaguar/Land Rover TPJLR 52.095 & 52.112
- Nissan NES M0402
Sensory inspections
Standard-compliant evaluation of the odors emitted by materials and components utilizing a trained panel of test subjects.
Test standards:
- VW PV3900
- VDA 270
- DIN ISO 16000-28
VOC screening – Microchamber (µ-chamber)
A fast and cost-effective yet reliable method that is well suited for the rapid identification of potential VOC sources, but also for the selection or development of low-emission materials.
Test standards:
- ISO 12219-3
- Jaguar/Land Rover TPJLR 52.104
Why TÜV Rheinland?
- Decades of experience in emissions testing
- ISO-accredited laboratory outfitted with state-of-the-art equipment
- OEM-compliant performance of all relevant test procedures
- Customized consulting services and testing strategies
Our experienced experts use state-of-the-art test methods to help you meet the highest quality requirements – ensuring clean air in vehicle interiors and happy customers.
More information on our vehicle accessory services, including an overview of all tests and test procedures, can be found here.
